51A22-01-1-04S

  • Optional complete seal for PC board assembly and cleaning
  • Small 1/2" diameter
  • Positive shaft grounding for EMI/RFI shielding
  • MIL Qualified: MIL-S-3786/35
  • Poles: up to 4
  • Angle of Throw: 22.5, 30
  • Positions: 12, 16
  • Rating (max): 200 mA
  • Depth Behind Panel-inches [mm]: 0.658 [16,71]
  • Termination: PC mount, solder lug
Link copied to clipboard. Request Quote
  • Technical Data
  • Description
  • Drawings
  • Downloads
  • Where to Buy
  • 3D Model AvailableNo
  • Angle of Throw (°)22.5
  • Behind Panel (in)0.739
  • Contact TypeShorting
  • Fixed StopFixed Stop
  • Maximum Switch Rating200 mA
  • Mechanical Life Cycles25,000
  • Military RatedNo
  • Number of Decks1
  • Number of Poles1
  • Ordering Part Number51A22-01-1-04S
  • OutputRotary
  • Positions per Pole4
  • Process SealNo
  • RoHS CompliantYes
  • Shaft & Panel SealNo
  • Shaft Diamter (in)0.125
  • Shaft StyleShaft
  • Stop Strength7.5 lbf in
  • TerminationSolder Lug
  • UL RatedNo
  • Optional complete seal for PC board assembly and cleaning
  • Small 1/2" diameter
  • Positive shaft grounding for EMI/RFI shielding
  • MIL Qualified: MIL-S-3786/35
  • Poles: up to 4
  • Angle of Throw: 22.5, 30
  • Positions: 12, 16
  • Rating (max): 200 mA
  • Depth Behind Panel-inches [mm]: 0.658 [16,71]
  • Termination: PC mount, solder lug
